MiCRA Technology Gateway is an industry-led research and development facility located in the CASH-Synergy Centre at TU Dublin (Tallaght Campus). Focusing on the advancement of Agri-Food sensing and In-Vitro Biodiagnostic technologies, the gateway consists of state-of-the-art electroanalytical, analytical, surface science, cell culture and microbiology labs/instrumentation, and sensor/prototype fabrication facilities.

The facility has a strong and growing portfolio of applied research, making knowledge and expertise accessible to local and national industry. Working extensively with a range of companies from start-ups through SMEs to global multinationals. The Gateways core technologies can be readily adapted to provide solutions for a range of challenges.

In sectors that include:

• Agri-Food Sensing Technology
• In-Vitro Biodiagnostics
• Sustainability & Environmental Testing
• Bio and Pharma Technology
• Analytical Services & Research
• Materials Research

MiCRA has access to a range of fully equipped research laboratories facilitating wet chemistry, sample preparation and electrochemical and spectroscopic analysis. The Gateway also has full access to the wider laboratory and analytical facilities across TU Dublin including: Chromatographic analysis, surface science, spectroscopic, particle size analysis and elemental analysis.

Current facilities available at MiCRA include:

Analytical Laboratories

We have two dedicated laboratories one for scanning electron microscopy, with two SEM instruments, one with EDX function, and the second which has 300 MHz and 500 MHz multi-nuclear NMR systems (can do solid state as well).

There is a large analytical instrumentation laboratory which houses a suite of spectroscopic and chromatographic equipment including a GC-MS (Agilent Technology); LC-MS Q-TOF Accurate-Mass (Agilent technologies 6530); Shmiadzu uHPLC and preparative LC systems; FT-IR, UV-vis spectrophotometer, and a polarimeter.

Chemical Synthesis Laboratory

Has benchspace and 11 high specification extraction fumehoods, serviced with gases for inert reactions. The laboratory is kitted out with ancillary equipment and glassware for advanced experimental chemical synthesis. It also houses specialist synthesis equipment, including a hyrdogenator, microwave synthesiser and a solid phase peptide synthesiser.

Electroanalytical Innovation Laboratory

This is used mainly for sensor fabrication and analysis with at least six different potentiostats for cyclic voltammetry, square wave voltammetry.

Pilot Plant

Fermentation Suite – up to 100L capacity with steam in place and clean in place facilities; 10L system and a 2L quad fermentation unit. Can be set up for microbial cell culture, but also has microspargers and marine type impellers for conversion to animal cell culture. All the fermenters have pH, pO2, turbidity and off gas analysis which feeds back to a MFCS data handling unit. For downstream processing there is Centrifuge 50L/hr (11,750 rpm) and a Millipore TFF unit for concentrating down product depending on the process.

BIOSTAT Cultibag RM 20/50 – This is a wave technology/disposable bag system for animal cell culture, up to 20L capacity currently, 50L possible with additional equipment.

Pilot Plant: Solid Formulations – 5 vessels ranging from 250Lto 500L; training instrumentation skid; centrally controlled by a PLC with SCADA interface for the user.

Other equipment in the Pilot Plant includes – Millipore K-Prime unit for larger scale chromatography projects; Bottling line with 500ml fill capacity fed from the main vessels in the lab; Pasteurising Unit.

PAT and Technology Transfer Laboratories

We have a 3000 sq ft Technology Development & Transfer Laboratory in the main building which houses a 2L automated Chemical Reactor, 10L 1 Pot Granulator / Dryer, Fluid Bed Dryer (Glatt), Homogeniser, Tablet Press, Powder Testing Equipment – e.g. Particle Size, Dissolution, Hardness, Friability, Disintegration, sieves. There is also a supporting process analytical laboratory (PAT Lab) with Raman and NIR spectrometers, particle size analyser, rheometer and thermoanalytical instruments, e.g. DSC, TGA.

Prototype and Fabrication Lab

The Prototype and Fabrication Lab allows for the rapid design and testing of a wide variety of electrochemical and microfluidic systems. Laboratory equipment includes:

• Potentiostat equipment and Multichannel Potentiostat suites with potentiostat/galvanostat/impedance capabilities to develop rapid sensors for various industry applications
• CAD software for chip and electrode design
• DEK 248 Screen printer: allowing for the patterning of electrodes, conductive tracks, and insulators
• Formulating facilities: preparation/modification of printing inks
• Dispenser for electrode modification and coating
• Electrodes and Microfluidics design and manufacturing
• Laser-cutter: fabrication of microfluidic channels
• Sonic bonder: assembling microfluidic chips
• Vastex D1 Series (D-100) Infrared Dryer

Class II Biosafety & Microbiology Laboratories

The microbiology laboratories at MiCRA Biodiagnostics is well equipped with facilities to handle general and Class I & II micro-organisms. Our laboratory equipment includes:

• Biological Safety Cabinet (Class II)
• Support Equipment (for the growth and preservation of micro-organisms in aerobic/anaerobic conditions)
• CO2 Incubator, Anaerobic jars, Incubator shakers, –20°C and –80°C Freezers, Refrigerator
• Electrochemical Workstations
• Potentiostats
• UV-VIS Spectrophotometer
• Optical Microscope
• Support Instrumentation
• Water Bath, Thermo-mixer, Balance, etc.
• Autoclaves for Sterilization and Waste Disposal

For more information on facilities and services available at MiCRA check out their website or contact the team.

Why light is so good for sensing

The application of light for sensing all phases, solid, liquid and gas is due to the many ways in which light interacts with the world around us. Light is a form of electromagnetic radiation, waves of different energies. The visible light we see in our everyday lives is a tiny fraction of the range of electromagnetic radiation available to us through technological advancements. We cannot sense radio waves, a form of electromagnetic radiation, in a room. However, if someone turns on a radio, we then recognize their presence and know they are around us. If our eyes detected radio waves, it would be of little use, as radio waves can travel through walls and we would just keep on hitting solid objects, because we just would not see them, as the waves do not interact with walls. However, when put to the right job, radio waves can be extremely useful in sensing. Significantly, in astronomy where they have been used to discover pulsars and quasars. Our bodies are sources of electromagnetic radiation, in what is known as the infrared (IR) region.

Our eyes also cannot detect IR radiation and for good reason. IR is strongly absorbed by atmospheric gases and struggles to penetrate through air, compared to visible radiation. The world around us would be very dark as all the IR light is blocked by just gas. The opposite of radio waves, we would see barriers all around us blocking light and we would not be able to tell the difference between air and a wall.

However, because of this strong interaction of IR with gases, this region of the electromagnetic spectrum is extremely powerful for detecting trace amounts of pollutants, such as ammonia and volatile organic compounds (VOCs), in the atmosphere. Just like our eyes evolved to select visible light for a purpose, at CAPPA, we select a certain region of the electromagnetic spectrum to serve your purpose of sensing.

The Light Fingerprint

Electromagnetic radiation is a form of wave, where shorter wavelengths have higher energy. Depending on the wavelength of the light and the structure or location of the molecule, light can be absorbed, and the molecule is energetically excited. This excitation is the crucial fingerprint, where light can excite a molecule to vibrate, rotate, translate or to move an electron. With sufficient energy, light can also remove an electron totally from the molecule or dissociate molecules. If light is polarized, we can also select the direction the molecule points. To form a visualization of this, exchange a gaseous methane molecule to a human. Methane molecules compromise four hydrogen atoms and a carbon atom, with the carbon located at the centre and the hydrogen atoms distributed around. In comparison, a human has four limbs (arms and legs) located around a centred torso. When visualising our control over methane with light, exchange the methane molecule with a human. By selecting a specific wave of light, we can control the human to move selected limbs in/out, arms or legs, (vibrational excitation) or rotate limbs/torso at different speeds (rotational excitation) or translate (translational excitation). With polarization, we can turn the human to look in a particular direction. Knowledge of the wavelengths of light, which produce these effects, which is exceptionally dependent on structure, is the fingerprint we use to identify the molecule.

Detection of Fingerprint

Knowing the location of the fingerprint in the electromagnetic spectrum is important but we also need to know how to take advantage of this interaction with light. There are several ways to identify the existence of the interaction. In all cases, a suitable light source is needed. CAPPA has a large collection of light sources with complimentary benefits. Table 1 illustrates a full list of available light sources.

Energy increases with decreasing wavelength; therefore, shorter wavelengths have the highest energy interaction, i.e. electronic excitation. These occur in the ultraviolet (UV) region, <400 nm<400 nm (where [Equation] is wavelength) and visible (VIS), 400 nm <<780 nm400 nm <<780 nm. With increasing wavelength vibrational transitions become dominant, in the Near-Infrared (NIR), 780 nm <<1400 nm780 nm <<1400 nm, and shortwave infrared (SWIR), 1400 nm <<2500 nm1400 nm <<2500 nm. At longer wavelengths, vibrational interactions remain strong and rotational transitions become more resolvable, in what is known as the Mid-Infrared, 2.5 μm <<11 μm2.5 μm <<11 μm.

The light sources illuminate the sample and if the target species is present, the absorption or scattering of light can be detected, both directly and indirectly.

In direct detection, the light intensity reflected or transmitted by the sample is measured, using detectors such as Photodiode, MCT, InSb, bolometers or photo-multiplier tubes. In some cases, the interaction of light may be weak, e.g. where concentrations are very low, making signal change difficult to detect. Several techniques are employed to increase the strength of interaction, such as phase shift interferometry (PSI) and cavity enhanced absorption (CEA) techniques. In PSI, the transmitted signal is mixed with another light signal to improve the contrast in the change of signal. In CEA, the sample is placed inside a cavity composed of highly reflective mirrors, where light can be trapped. Consequently, light trapped inside the cavity can travel through the sample up to hundreds of thousands of times, greatly increasing the interaction path length.

Direct absorption is the simplest technique, but not always the best. Sometimes, using indirect techniques can result in stronger signal, and importantly creates no signal when the sample is not present, in contrast to direct methods. Indirect methods involve measuring the relaxation processes occurring after light excitation. A molecule can relax in several procedures, including light emission and collisional. In fluorescence spectroscopy, light emitted by the sample after electronic excitation is a measure. Valuable information about the sample can be determined both by the timing of the emission and the wavelength of the emitted light. In photoacoustic spectroscopy, the excited molecule is cooled by collisions with neighbouring molecules, creating heating and consequently, sound waves. A microphone is used to measure the sound and the concentration of the sample can be calculated. In thermal imaging, IR light emitted directly by excited bodies is imaged.

Industry Application

Selecting the best light region, interaction and detection technique is a function of the sample type and location. Table 1 shows a sample list of the industries, in which different wavelength regions and detection techniques can be employed. Crucially, the expertise at CAPPA can be of assistance to select the best detection technique for your process or application.

One such industry example is the Quantum Cascade Laser (QCL) light source. CAPPA has a QCL in the wavelength range short-wave infrared to medium wavelength infrared (SWIR – MIR). The output facet of the QCL is small enough that the light emitted can be imaged to a diffraction-limited spot, enabling the analysis of miniature targets, such as fibers or micro-defects, from long distances. The high power of the source also enables imaging of large areas, in both reflection and transmission modes, to study coatings, microplastics or protein distribution. The sharp linewidth, of approx. 3 MHz, allows application in trace, low concentration, gas sensing, using techniques such as wavelength modulation and photoacoustic spectroscopy. These valuable tools make the QCL applicable in a range of fields from agriculture, environment, energy, astronomy, electricity, pharmaceutical, biology and health.

CAPPA has a wide range of industry experience in a variety of wavelengths, techniques and sectors. CAPPA offers a number of avenues for companies to explore photonics solutions to their development needs, offering services such as research, product development, process improvement and consultancy. CAPPA has worked with a variety of companies in sectors ranging from medical, device, pharmaceutical, telecommunications, consumer electronics, medical diagnostics, analytical equipment, baby products, semiconductors, fragrance, food and beverage.

CAPPA have worked on a variety of projects including development of a swallowable capsule for detection of intestinal bleeding, FTIR and Raman analysis of cheese maturity for Four Star Pizza, UV irradiance, dose and flow characterisation of air sterilization appliance, UVC (254nm) irradiance and dose measurements on mobile room sterilizer, in-depth processing and analysis of heard data, and R&D for an advanced optical inspection system.

Conclusion

The electromagnetic spectrum is the most powerful diagnostic tool we have. Using light, we have found ways to do everything from determining the age of the universe, the concentration of sulphur hexafluoride in the atmosphere down to the parts-per-trillion level and the location of a broken bone in a body. Even so, presently there are more and more applications of light being found. Light is revolutionizing areas such as communication and energy. At CAPPA, we want to highlight the opportunities light creates to Irish enterprises.

You can learn more about the facilities available at CAPPA here and more about the service offering available for various industries here.

The Engineering, Materials, and Design (EMD) Ireland cluster of the Enterprise Ireland Technology Gateway provides specialised technical support, guidance, and assistance to Irish companies of all sizes. For companies wishing to acquire knowledge in research, development, and innovation, EMD Ireland can provide vast experience in the implementation of close-to-market solutions.

Who are EMD Ireland?  

EMD Ireland consists of seven Technology Gateways specialising in areas such as energy, precision engineering, polymers, protective coatings, prototype design, medical imaging technologies and 3D medal additive manufacturing. With skills, knowledge, and expertise in a variety of industries, the EMD Ireland team strives to equip Irish businesses with the essential aids and supports to advance the growth of RD&I throughout Ireland.

Companies who choose to work with EMD Ireland benefit from the use of the extensive linked resources available, resulting in a more unified and timely approach to innovation. The team of Gateway Managers and Business Development researchers and engineers works on both large and small projects with a diverse spectrum of clients. You do not need to be a client of Enterprise Ireland to collaborate with the cluster.  Collaboration within the cluster is key, allowing continuous transfer of shared skills and experiences within the cluster, a benefit which can unlock many doors for Irish businesses. Companies also benefit from an availability of professional guidance and expertise, flexibility in approach, and a high degree of cluster member engagement. Companies frequently discover that the cluster becomes a crucial extension of their total R&D capabilities during the product development process.

What to expect?

Every innovation journey starts with the creation of a new idea or the acknowledgement of an existing problem within a product or process. All 16 Gateways have a dedicated manager, business development staff and team of researchers and engineers who act as key contact points for industry. If you know which Gateway is the most suitable for your project, make contact with the relevant Gateway Manager, if not your regional Gateway Manager will be able to assist in referring you to the most appropriate Gateway.

At this early stage the team will work with you to outline your company need. Should your project require expertise from multiple gateways, this transition will be managed in-house by your lead gateway, aiding in process efficiency as well as adherence to financial and timetable expectations.

Funding and supports can often be critical in allowing a company to proceed with a project. A discussion will take place detailing the various funding options open to you, providing detail on the application process and eligibility for funding. Companies often find funding applications stressful, don’t worry our Gateway teams are here to help every step of the way with support, guidance and advice on submitting your application.

You can also expect to discuss deliverables and timelines. Agreeing on deliverables at this stage means there will be no unexpected surprises further along the road. It also ensures the project runs smoothly, on time and on budget.

Once everything is in place and funding has been approved, your project will commence on the start date agreed and will be managed throughout by your lead Gateway team, who will also update you on how your project is progressing. You will be informed when your project has been completed and provided with the agreed outcome as laid out in the project deliverables.

How can you get started?  

The cluster has a dedicated support office and team to help with your companies’ individual needs. If you have an idea for a new product, service or process or are experiencing difficulties with an existing process, get in touch with us to see how we can assist you in developing an innovative solution.
